BS6883 Cable

Elastomer insulated cables for fixed wiring in ships (shipwiring) and on mobile and fixed offshore marine units manufactured in accordance with British Standard BS6883

BS6883 Cable

British Standard BS6883 covers the specifications for the shipboard fixed wiring of lighting, power, control, instrumentation and propulsion circuits with a voltage rating of up to 8.7/15kV. It also covers these same cables used in mobile and fixed offshore units.

This Standard specifies the requirements and test methods for a wide variety of cables up to and including 8.7/15kV. The cables are manufactured with low smoke halogen free materials which is an important factor in minimising the risk to human lives and sensitive equipment in the event of a fire on board a marine unit.

This Standard is complemented by BS7917 which covers the requirements for fire resistance (limited circuit integrity).

BS6883 Cable designation

This Standard classifies the BS6883 ship wiring cables and offshore cables according to the following designations:

BS6883 Type SW2 Heavy-duty enhanced oil-resisting, flame retardant, with reduced halogen gas emission
BS6883 Type SW3 Ordinary duty oil-resisting with low emission of smoke and corrosive gases when affected by fire
BS6883 Type SW4 Ordinary duty enhanced oil-resisting with low emission of smoke and gases when affected by fire

BS6883 cable construction


150/250V
(pairs / triples / quads)
Single and multicore
600/1000V, 1.9/3.3kV and 3.3/3.3kV
Single and multi-core
3.8/6.6kV, 6.6/6.6kV and 6.35/11kV
Conductor Tinned annealed copper (Class 2) Tinned annealed copper (Class 2 or Class 5) of sizes 1mm2 and 1.5mm2, and Class 2 of all other conductor sizes Tinned annealed copper (Class 2)
Conductor screen - - Textile fabric proofed semi-conducting tape screen
Insulation Type G4 Type GP4 for 600/1000V and Type GP5 for 1.9/3.3kV and 3.3/3.3kV Type GP5
Screen / Tape Laminated screening tape Proofed tape, if applicable Proofed tape, if applicable
Inner sheath Chosen in relation to SW Type
Wire braid Galvanised mild steel, tinned annealed copper or tinned bronze
Outersheath Type SW2, Type SW3 or Type SW4

BS6883 Outer sheath colours

This Standard specifies the following outersheath colours:

Instrumentation cables - 150/250V Grey
Single and multi-core cables - 600/1000V Black
High Voltage - >600/1000V Red

As a shipwiring cable UK supplier, Eland Cables has a wide range of marine & offshore cable including the Type SW4 cable, holding Lloyd's Register approval for use in fixed wiring on ships, offshore platforms and drilling units. Please see our offshore cable specification sheets or speak to our technical experts for more information.
