657TQ / 658TS / 6571TQ - Type SW4 Cables
Eland Cables is a leading supplier of SW4 marine industry cable for power, lighting and control applications, manufactured in accordance with British Standard BS6883.
657TQ, 6571TQ, 658TQ Cable Specification
Our Shipboard Type SW4 wiring includes armoured (658TQ) and unarmoured (657TQ) cables designed for fixed wiring installations across all areas onboard ships and offshore units. Applications include accommodation and open deck. It also includes the unarmoured 6571TQ, an unarmoured cable designed to prevent the risk of electric shock in the event of fault or surge.
The cables have a voltage rating of 1000V with a heat and oil resistant, and flame retardant sheathing (HOFR). These cables are all halogen-free to reduce the risk to human life or to sensitive equipment by limiting the emission of smoke, noxious fumes and acid forming gases in the event of a fire.
The cables are designed to operate within a temperature range of -40oC to +90oC when flexed.
SW4 Cable Type - Datasheets
SW4 cables are ordinary duty cables with an enhanced oil resistance and low smoke and gases emissions when subject to fire. These properties are detailed on the attached technical datasheets alongside key dimensional and electrical data.
Type SW2 cables for heavy duty requirements are also available.
This range of cables is flame retardant to BS EN 50266-2-2 Category A/F and to IEC 60332-3-22. Their smoke emission is compliant to BS EN /IEC 61034-2, and their corrosive gas emission is compliant to BS EN 50267-2-1 and IEC 60754-1: Acid gas for type SW4 cables (0.5% HCL or less).
This range is approved by the Lloyd's Register.
More information
Cable Selection: Type SW4 657 TQ cable / 658 TQ cable/ 6571 TQ cable
We are highly experienced in the supply of marine power, lighting and control cables. Please call us to discuss your project requirements for 657TQ, 658TQ and 6571TQ cables or for other marine cables.
Construction Table
BS 6883 657TQ Type SW4 Cable
|
BS 6883 / 658TQ Type SW4 Armoured Cable
|
BS 6883 6571TQ Type SW4 Cable
|
|
|---|---|---|---|
| VOLTAGE | 0.6/1kV | ||
| CONDUCTOR | 1.0mm2 to 1.5mm2: Class 5 Flexible Stranded Tinned Copper | Class 2 Stranded Tinned Copper | |
| INSULATION | Halogen-Free Elastomer EPR | ||
| INNER SHEATH | - | HOFR (Heat and Oil Resistant and Flame Retardant), Halogen-Free Elastomer | - |
| ARMOUR | - | Galvanised Steel Wire Braid | - |
| SEPARATOR | - | Suitable Tape between the Braid and Outer Sheath | - |
| OUTER SHEATH | HOFR (Heat and Oil Resistant and Flame Retardant), Halogen-Free Elastomer | ||
657TQ / 658TS / 6571TQ - Type SW4 Cables
3 product(s)
YOUR CABLE OPTIONS
Use the FastQuote filters to find the exact cable specifications you need.
Need a bespoke solution? Learn more about customised cables.
| Product name | Part No | Cores | Nominal cross-sectional area (mm²) | Sheath colour | Length (m) | |
|---|---|---|---|---|---|---|
| BS 6883 657TQ Type SW4 Cable | ASH1010BK | 1 | 1mm² | Black | ||
| BS 6883 657TQ Type SW4 Cable | ASH1015BK | 1 | 1.5mm² | Black | ||
| BS 6883 657TQ Type SW4 Cable | ASH1025BK | 1 | 2.5mm² | Black | ||
| BS 6883 657TQ Type SW4 Cable | ASH1040BK | 1 | 4mm² | Black | ||
| BS 6883 657TQ Type SW4 Cable | ASH1060BK | 1 | 6mm² | Black | ||
| BS 6883 657TQ Type SW4 Cable | ASH110BK | 1 | 10mm² | Black | ||
| BS 6883 657TQ Type SW4 Cable | ASH116BK | 1 | 16mm² | Black | ||
| BS 6883 657TQ Type SW4 Cable | ASH125BK | 1 | 25mm² | Black | ||
| BS 6883 657TQ Type SW4 Cable | ASH135BK | 1 | 35mm² | Black | ||
| BS 6883 657TQ Type SW4 Cable | ASH150BK | 1 | 50mm² | Black | ||
| BS 6883 657TQ Type SW4 Cable | ASH170BK | 1 | 70mm² | Black | ||
| BS 6883 657TQ Type SW4 Cable | ASH195BK | 1 | 95mm² | Black | ||
| BS 6883 657TQ Type SW4 Cable | ASH1120BK | 1 | 120mm² | Black | ||
| BS 6883 657TQ Type SW4 Cable | ASH1150BK | 1 | 150mm² | Black | ||
| BS 6883 657TQ Type SW4 Cable | ASH1185BK | 1 | 185mm² | Black | ||
| BS 6883 657TQ Type SW4 Cable | ASH1240BK | 1 | 240mm² | Black | ||
| BS 6883 657TQ Type SW4 Cable | ASH1300BK | 1 | 300mm² | Black | ||
| BS 6883 657TQ Type SW4 Cable | ASH1400BK | 1 | 400mm² | Black | ||
| BS 6883 657TQ Type SW4 Cable | ASH1500BK | 1 | 500mm² | Black | ||
| BS 6883 657TQ Type SW4 Cable | ASH20010 | 2 | 1mm² | Black | ||
| BS 6883 657TQ Type SW4 Cable | ASH20015 | 2 | 1.5mm² | Black | ||
| BS 6883 657TQ Type SW4 Cable | ASH20025 | 2 | 2.5mm² | Black | ||
| BS 6883 657TQ Type SW4 Cable | ASH20040 | 2 | 4mm² | Black | ||
| BS 6883 657TQ Type SW4 Cable | ASH20060 | 2 | 6mm² | Black | ||
| BS 6883 657TQ Type SW4 Cable | ASH2010 | 2 | 10mm² | Black | ||
| BS 6883 657TQ Type SW4 Cable | ASH2016 | 2 | 16mm² | Black | ||
| BS 6883 657TQ Type SW4 Cable | ASH2025 | 2 | 25mm² | Black | ||
| BS 6883 657TQ Type SW4 Cable | ASH2035 | 2 | 35mm² | Black | ||
| BS 6883 657TQ Type SW4 Cable | ASH2050 | 2 | 50mm² | Black | ||
| BS 6883 657TQ Type SW4 Cable | ASH2070 | 2 | 70mm² | Black | ||
| BS 6883 657TQ Type SW4 Cable | ASH2095 | 2 | 95mm² | Black | ||
| BS 6883 657TQ Type SW4 Cable | ASH2120 | 2 | 120mm² | Black | ||
| BS 6883 657TQ Type SW4 Cable | ASH2150 | 2 | 150mm² | Black | ||
| BS 6883 657TQ Type SW4 Cable | ASH30010 | 3 | 1mm² | Black | ||
| BS 6883 657TQ Type SW4 Cable | ASH30015 | 3 | 1.5mm² | Black | ||
| BS 6883 657TQ Type SW4 Cable | ASH30025 | 3 | 2.5mm² | Black | ||
| BS 6883 657TQ Type SW4 Cable | ASH30040 | 3 | 4mm² | Black | ||
| BS 6883 657TQ Type SW4 Cable | ASH30060 | 3 | 6mm² | Black | ||
| BS 6883 657TQ Type SW4 Cable | ASH3010 | 3 | 10mm² | Black | ||
| BS 6883 657TQ Type SW4 Cable | ASH3016 | 3 | 16mm² | Black | ||
| BS 6883 657TQ Type SW4 Cable | ASH3025 | 3 | 25mm² | Black | ||
| BS 6883 657TQ Type SW4 Cable | ASH3035 | 3 | 35mm² | Black | ||
| BS 6883 657TQ Type SW4 Cable | ASH3050 | 3 | 50mm² | Black | ||
| BS 6883 657TQ Type SW4 Cable | ASH3070 | 3 | 70mm² | Black | ||
| BS 6883 657TQ Type SW4 Cable | ASH3095 | 3 | 95mm² | Black | ||
| BS 6883 657TQ Type SW4 Cable | ASH70015 | 7 | 1.5mm² | Black | ||
| BS 6883 657TQ Type SW4 Cable | ASH70025 | 7 | 2.5mm² | Black | ||
| BS 6883 657TQ Type SW4 Cable | ASH120015 | 12 | 1.5mm² | Black | ||
| BS 6883 657TQ Type SW4 Cable | ASH120025 | 12 | 2.5mm² | Black | ||
| BS 6883 657TQ Type SW4 Cable | ASH190015 | 19 | 1.5mm² | Black | ||
| BS 6883 657TQ Type SW4 Cable | ASH190025 | 19 | 2.5mm² | Black | ||
| BS 6883 657TQ Type SW4 Cable | ASH270015 | 27 | 1.5mm² | Black | ||
| BS 6883 657TQ Type SW4 Cable | ASH370015 | 37 | 1.5mm² | Black | ||
| BS 6883 657TQ Type SW4 Cable | ASH4010 | 4 | 1mm² | Black | ||
| BS 6883 657TQ Type SW4 Cable | ASH4015 | 4 | 1.5mm² | Black | ||
| BS 6883 657TQ Type SW4 Cable | ASH4025 | 4 | 2.5mm² | Black | ||
| BS 6883 657TQ Type SW4 Cable | ASH4040 | 4 | 4mm² | Black | ||
| BS 6883 657TQ Type SW4 Cable | ASH4060 | 4 | 6mm² | Black | ||
| BS 6883 657TQ Type SW4 Cable | ASH410 | 4 | 10mm² | Black | ||
| BS 6883 657TQ Type SW4 Cable | ASH416 | 4 | 16mm² | Black | ||
| BS 6883 657TQ Type SW4 Cable | ASH425 | 4 | 25mm² | Black | ||
| BS 6883 657TQ Type SW4 Cable | ASH435 | 4 | 35mm² | Black | ||
| BS 6883 657TQ Type SW4 Cable | ASH450 | 4 | 50mm² | Black | ||
| BS 6883 657TQ Type SW4 Cable | ASH470 | 4 | 70mm² | Black | ||
| BS 6883 657TQ Type SW4 Cable | ASH495 | 4 | 95mm² | Black | ||
| BS 6883 657TQ Type SW4 Cable | ASH4120 | 4 | 120mm² | Black | ||
| BS 6883 657TQ Type SW4 Cable | ASH4150 | 4 | 150mm² | Black | ||
| BS 6883 657TQ Type SW4 Cable | ASH5015 | 5 | 1.5mm² | Black | ||
| BS 6883 657TQ Type SW4 Cable | ASH5025 | 5 | 2.5mm² | Black | ||
| BS 6883 657TQ Type SW4 Cable | ASH5040 | 5 | 4mm² | Black | ||
| BS 6883 657TQ Type SW4 Cable | ASH5060 | 5 | 6mm² | Black | ||
| BS 6883 657TQ Type SW4 Cable | ASH510 | 5 | 10mm² | Black | ||
| BS 6883 657TQ Type SW4 Cable | ASH3120 | 3 | 120mm² | Black | ||
| BS 6883 657TQ Type SW4 Cable | ASH2150 | 3 | 150mm² | Black | ||
| BS 6883 657TQ Type SW4 Cable | ASH3185 | 3 | 185mm² | Black | ||
| BS 6883 657TQ Type SW4 Cable | ASH3240 | 3 | 240mm² | Black | ||
| BS 6883 / 658TQ Type SW4 Armoured Cable | ASH2010GSWB | 2 | 1mm² | Black | ||
| BS 6883 / 658TQ Type SW4 Armoured Cable | ASH2015GSWB | 2 | 1.5mm² | Black | ||
| BS 6883 / 658TQ Type SW4 Armoured Cable | ASH2025GSWB | 2 | 2.5mm² | Black | ||
| BS 6883 / 658TQ Type SW4 Armoured Cable | ASH2040GSWB | 2 | 4mm² | Black | ||
| BS 6883 / 658TQ Type SW4 Armoured Cable | ASH2060GSWB | 2 | 6mm² | Black | ||
| BS 6883 / 658TQ Type SW4 Armoured Cable | ASH210GSWB | 2 | 10mm² | Black | ||
| BS 6883 / 658TQ Type SW4 Armoured Cable | ASH216GSWB | 2 | 16mm² | Black | ||
| BS 6883 / 658TQ Type SW4 Armoured Cable | ASH225GSWB | 2 | 25mm² | Black | ||
| BS 6883 / 658TQ Type SW4 Armoured Cable | ASH235GSWB | 2 | 35mm² | Black | ||
| BS 6883 / 658TQ Type SW4 Armoured Cable | ASH250GSWB | 2 | 50mm² | Black | ||
| BS 6883 / 658TQ Type SW4 Armoured Cable | ASH270GSWB | 2 | 70mm² | Black | ||
| BS 6883 / 658TQ Type SW4 Armoured Cable | ASH295GSWB | 2 | 95mm² | Black | ||
| BS 6883 / 658TQ Type SW4 Armoured Cable | ASH2120GSWB | 2 | 120mm² | Black | ||
| BS 6883 / 658TQ Type SW4 Armoured Cable | ASH2150GSWB | 2 | 150mm² | Black | ||
| BS 6883 / 658TQ Type SW4 Armoured Cable | ASH2185GSWB | 2 | 185mm² | Black | ||
| BS 6883 / 658TQ Type SW4 Armoured Cable | ASH2240GSWB | 2 | 240mm² | Black | ||
| BS 6883 / 658TQ Type SW4 Armoured Cable | ASH2300GSWB | 2 | 300mm² | Black | ||
| BS 6883 / 658TQ Type SW4 Armoured Cable | ASH3010GSWB | 3 | 1mm² | Black | ||
| BS 6883 / 658TQ Type SW4 Armoured Cable | ASH3015GSWB | 3 | 1.5mm² | Black | ||
| BS 6883 / 658TQ Type SW4 Armoured Cable | ASH3025GSWB | 3 | 2.5mm² | Black | ||
| BS 6883 / 658TQ Type SW4 Armoured Cable | ASH3040GSWB | 3 | 4mm² | Black | ||
| BS 6883 / 658TQ Type SW4 Armoured Cable | ASH3060GSWB | 3 | 6mm² | Black | ||
| BS 6883 / 658TQ Type SW4 Armoured Cable | ASH310GSWB | 3 | 10mm² | Black | ||
| BS 6883 / 658TQ Type SW4 Armoured Cable | ASH316GSWB | 3 | 16mm² | Black | ||
| BS 6883 / 658TQ Type SW4 Armoured Cable | ASH325GSWB | 3 | 25mm² | Black | ||
| BS 6883 / 658TQ Type SW4 Armoured Cable | ASH335GSWB | 3 | 35mm² | Black | ||
| BS 6883 / 658TQ Type SW4 Armoured Cable | ASH350GSWB | 3 | 50mm² | Black | ||
| BS 6883 / 658TQ Type SW4 Armoured Cable | ASH370GSWB | 3 | 70mm² | Black | ||
| BS 6883 / 658TQ Type SW4 Armoured Cable | ASH395GSWB | 3 | 95mm² | Black | ||
| BS 6883 / 658TQ Type SW4 Armoured Cable | ASH3120GSWB | 3 | 120mm² | Black | ||
| BS 6883 / 658TQ Type SW4 Armoured Cable | ASH3150GSWB | 3 | 150mm² | Black | ||
| BS 6883 / 658TQ Type SW4 Armoured Cable | ASH3185GSWB | 3 | 185mm² | Black | ||
| BS 6883 / 658TQ Type SW4 Armoured Cable | ASH3240GSWB | 3 | 240mm² | Black | ||
| BS 6883 / 658TQ Type SW4 Armoured Cable | ASH3300GSWB | 3 | 300mm² | Black | ||
| BS 6883 / 658TQ Type SW4 Armoured Cable | ASH4010GSWB | 4 | 1mm² | Black | ||
| BS 6883 / 658TQ Type SW4 Armoured Cable | ASH4015GSWB | 4 | 1.5mm² | Black | ||
| BS 6883 / 658TQ Type SW4 Armoured Cable | ASH4025GSWB | 4 | 2.5mm² | Black | ||
| BS 6883 / 658TQ Type SW4 Armoured Cable | ASH4040GSWB | 4 | 4mm² | Black | ||
| BS 6883 / 658TQ Type SW4 Armoured Cable | ASH4060GSWB | 4 | 6mm² | Black | ||
| BS 6883 / 658TQ Type SW4 Armoured Cable | ASH4010GSWB | 4 | 10mm² | Black | ||
| BS 6883 / 658TQ Type SW4 Armoured Cable | ASH4016GSWB | 4 | 16mm² | Black | ||
| BS 6883 / 658TQ Type SW4 Armoured Cable | ASH425GSWB | 4 | 25mm² | Black | ||
| BS 6883 / 658TQ Type SW4 Armoured Cable | ASH435GSWB | 4 | 35mm² | Black | ||
| BS 6883 / 658TQ Type SW4 Armoured Cable | ASH450GSWB | 4 | 50mm² | Black | ||
| BS 6883 / 658TQ Type SW4 Armoured Cable | ASH470GSWB | 4 | 70mm² | Black | ||
| BS 6883 / 658TQ Type SW4 Armoured Cable | ASH495GSWB | 4 | 95mm² | Black | ||
| BS 6883 / 658TQ Type SW4 Armoured Cable | ASH4120GSWB | 4 | 120mm² | Black | ||
| BS 6883 / 658TQ Type SW4 Armoured Cable | ASH4150GSWB | 4 | 150mm² | Black | ||
| BS 6883 / 658TQ Type SW4 Armoured Cable | ASH4185GSWB | 4 | 185mm² | Black | ||
| BS 6883 / 658TQ Type SW4 Armoured Cable | ASH4240GSWB | 4 | 240mm² | Black | ||
| BS 6883 / 658TQ Type SW4 Armoured Cable | ASH4300GSWB | 4 | 300mm² | Black | ||
| BS 6883 / 658TQ Type SW4 Armoured Cable | ASH5015GSWB | 5 | 1.5mm² | Black | ||
| BS 6883 / 658TQ Type SW4 Armoured Cable | ASH5025GSWB | 5 | 2.5mm² | Black | ||
| BS 6883 / 658TQ Type SW4 Armoured Cable | ASH7015GSWB | 7 | 1.5mm² | Black | ||
| BS 6883 / 658TQ Type SW4 Armoured Cable | ASH7025GSWB | 7 | 2.5mm² | Black | ||
| BS 6883 / 658TQ Type SW4 Armoured Cable | ASH12015GSWB | 12 | 1.5mm² | Black | ||
| BS 6883 / 658TQ Type SW4 Armoured Cable | ASH12025GSWB | 12 | 2.5mm² | Black | ||
| BS 6883 / 658TQ Type SW4 Armoured Cable | ASH19015GSWB | 19 | 1.5mm² | Black | ||
| BS 6883 / 658TQ Type SW4 Armoured Cable | ASH19025GSWB | 19 | 2.5mm² | Black | ||
| BS 6883 / 658TQ Type SW4 Armoured Cable | ASH27015GSWB | 27 | 1.5mm² | Black | ||
| BS 6883 / 658TQ Type SW4 Armoured Cable | ASH27025GSWB | 27 | 2.5mm² | Black | ||
| BS 6883 / 658TQ Type SW4 Armoured Cable | ASH37015GSWB | 37 | 1.5mm² | Black | ||
| BS 6883 6571TQ Type SW4 Cable | ASH10010 | 1 | 1mm² | Green/Yellow | ||
| BS 6883 6571TQ Type SW4 Cable | ASH10015 | 1 | 1.5mm² | Green/Yellow | ||
| BS 6883 6571TQ Type SW4 Cable | ASH10025 | 1 | 2.5mm² | Green/Yellow | ||
| BS 6883 6571TQ Type SW4 Cable | ASH1004 | 1 | 4mm² | Green/Yellow | ||
| BS 6883 6571TQ Type SW4 Cable | ASH1006 | 1 | 6mm² | Green/Yellow | ||
| BS 6883 6571TQ Type SW4 Cable | ASH1010 | 1 | 10mm² | Green/Yellow | ||
| BS 6883 6571TQ Type SW4 Cable | ASH1016 | 1 | 16mm² | Green/Yellow | ||
| BS 6883 6571TQ Type SW4 Cable | ASH1025 | 1 | 25mm² | Green/Yellow | ||
| BS 6883 6571TQ Type SW4 Cable | ASH1035 | 1 | 35mm² | Green/Yellow | ||
| BS 6883 6571TQ Type SW4 Cable | ASH1050 | 1 | 50mm² | Green/Yellow | ||
| BS 6883 6571TQ Type SW4 Cable | ASH1070 | 1 | 70mm² | Green/Yellow | ||
| BS 6883 6571TQ Type SW4 Cable | ASH1095 | 1 | 95mm² | Green/Yellow | ||
| BS 6883 6571TQ Type SW4 Cable | ASH10120 | 1 | 120mm² | Green/Yellow | ||
| BS 6883 6571TQ Type SW4 Cable | ASH10150 | 1 | 150mm² | Green/Yellow | ||
| BS 6883 6571TQ Type SW4 Cable | ASH10185 | 1 | 185mm² | Green/Yellow | ||
| BS 6883 6571TQ Type SW4 Cable | ASH10240 | 1 | 240mm² | Green/Yellow | ||
| BS 6883 6571TQ Type SW4 Cable | ASH10300 | 1 | 300mm² | Green/Yellow | ||
| BS 6883 6571TQ Type SW4 Cable | ASH10400 | 1 | 400mm² | Green/Yellow | ||
| BS 6883 6571TQ Type SW4 Cable | ASH10500 | 1 | 500mm² | Green/Yellow |
