Customised Cable Solutions

Cable Design Consultancy

Customised solutions for bespoke applications and installations

Our portfolio of cables cover a broad spectrum of applications across an equally broad range of industries, but there are times when those products won’t quite meet the requirements of your application. It’s then that the combination of expert technical advice, coupled with our experience in cable R&D, can make the difference. Our cable design consultancy and a custom cable can be a cost-effective solution to your application conundrums.

What do we mean by customised cables?

Customised cables can cover a wide range of services, from designing a wholly bespoke cable against a unique specification, to adapting and changing existing cables to improve efficiency or overcome the limitations of a particular installation. Cable harnesses with high quality terminations, designed to your precise requirements, are also available as a cost-effective and time-saving pre-installation solution.

With all our custom cable solutions, after our experts have confirmed the cable design, we can have the cable manufactured in low minimum order quantities on short lead-times, have it rigorously tested in our in-house laboratory to confirm performance, and then delivered to you ready for installation. Where required, The Cable Lab® can also support you with any additional third-party approvals necessary for the cable, with the UKAS accredited facility being able to demonstrate compliance through its testing regimen.

Our technical experts have experience creating custom designed cable solutions for highly regulated organisations such as Network Rail and other leading utilities, for whom we regularly develop new cables, and for large-scale global projects such as Data Centres where the particular design or installation environment can dictate the need for this solution.

Our Customised Cable Solutions

Custom designed cable
Fully bespoke design developed by our technical experts against a unique application's specification

Composite cable
Used in many industries and particularly beneficial where there is a common and aggressive environment form which to protect the cable, or to reduce installation time (eg: cable pulling) and complexity. Composite cables may be manufactured by laying (twisting) complete cables of different or similar designs together, or placing the assembly under a collective armour layer and/or a final collective sheath.

Braiding, armouring and electrical screening
These options can place additional mechanical / electrical / EMI layers on an existing cable. Mechanical protection can be provided by adding either a flexible galvanised steel wire braid or simply more steel wire armour. Protection from electrical interference can be achieved by adding a metallic screen, such as a tinned copper braid or an aluminium/polyester foil.

Oversheathing and Resheathing
Whether extruding a new sheath over an existing product or resheathing in order to maintain the original overall product dimensions, this customisation can offer protection against environmental damage and enhance product performance  to support a long service life.

Oversheathing often involves a sheath colour change whether for cable identification or to provide additional environmental protection and UV stability. For outdoor use, cables can be oversheathed with weather-resistant materials such as Polyethylene (PE) and Polyurethane (PUR) making them suitable for use in ducts and harsh environments. The colour change options are extensive.

Note: any such changes may affect any pre-existing compliance, such as CPR, and may require recertification and retesting by appropriate regulatory bodies.

Cable harnessing
Cables pre-terminated with crimped lugs or glands, cut to precise lengths and, where appropriate, bundled and with cable markers, can offer economies in both time and money when replicated for frequent installations. These can be single lengths or multiple cables running a complex design route. See our cable harnessing page for more information.






Bespoke Cable Testing

All customised cables designed by The Cable Lab will be subject to testing to relevant standards or, where more appropriate, performance criteria such as conductor resistanceinsulation tensile and elongation, and vertical flame propagation. Independent cable testing will be conducted under our UKAS accreditation and, where required by industry or application, we can submit for relevant cable certification and cable approval processes.

For more information or to discuss possible custom designed cable solutions, please complete an enquiry form, contact our technical experts on the Technical Hotline +44 (0)20 7241 8500, or email technical@elandcables.com.
