Rolling Stock Cable

Rolling stock cables form part of a vast product range encompassing all cables used by moving vehicles across railway, metro and underground rail infrastructures. These are used for power, control, communications, heating and ventilation inside the vehicles. The cables are required to have mechanical and thermal properties that protect them from the stresses of movement and temperature extremes. Externally fitted cables must also possess good ultra-violet (UV), ozone, mineral oil, and fuel oil resistance. Some Rolling Stock cables are smaller than many other railway cabling to reduce weight and aid installation, with varying thickness of insulation wall depending on application.

Eland Cables supplies cables covering the full range of rolling stock applications, including United Kingdom manufactured rolling stock cable approved for use across Network rail lines and London Underground (LUL) infrastructures.

Fastquote En

Your tailored quote direct to your inbox

Your basket is currently empty

More information

LUL-Approved LFH rolling stock and their applications

Rail Rolling Stock Part 6 Type I Reduced wall single core cable - 600/1000V
Rail Rolling Stock Part 6 Type II standard wall single core cable 600/1000V
Rail Rolling Stock Part 6 Type III Enhanced wall single core cable - 600/1000V
Rail Rolling Stock Part 6 Type IV Reduced wall single core cable - 30/50V
Rail Rolling Stock Part 6 Type V Standard wall single core cable - 30/50V
Rail Rolling Stock Part 6 Type VI Standard wall multi-core cable with enhanced sheath - 600/1000V
Rail Rolling Stock Part 6 Type VII Standard wall multi-core cable with enhanced sheath - 30/50V
Rail Rolling Stock Part 6 Type VIII Standard wall pair and multi-pair cable with standard or enhanced sheath - 30/50V
Rail Rolling Stock Part 6 Type IX Reduced wall pair and multi-pair cable with standard sheath - 30/50V
Rail Rolling Stock Part 6 Type XI Reduced wall pair and multi-pair cable with standard sheath - 600/1000V
Rail Rolling Stock Part 6 Type XII Standard wall single core - 300/500V
Rail Rolling Stock Part 6 Type XIII Standard wall multi-core cable with enhanced sheath - 300/500V

All of the above cables have an LFH insulation. They are manufactured in accordance with RSE/STD/024 Part 6 Type I to IX and XI to XIII respectively, and 1-085 (Emissions and Flame Propagation).

Rolling stock cables manufactured to other international standards

In addition to LUL-approved LFH cables manufactured to Part 6 Type 1 to 13, we supply standard wall rolling stock that comply to EN50264-2-1 and EN50264-2-2, reduced wall cables to EN50264-3-1 and EN50264-3-2, and thin wall cables in accordance with EN50306-2, EN50306-3 and EN50306-4.

Other rolling stock cables in our range include high temperature cables manufactured in accordance with EN50382-2, RIA jumper cables and Transcab cables.

For more information on our rail portfolio, including rail power, telecoms, signalling cables and overhead line wires please speak to our industry experts who will be pleased to advice on your specific application requirements.

YOUR CABLE OPTIONS

Use the FastQuote filters to find the exact cable specifications you need.

Need a bespoke solution? Learn more about customised cables.

Reset

Product name Part No Cores Pairs Nominal cross-sectional area (mm²) Voltage Rating Sheath colour Length (m)
AEI Rolling Stock A3UBK0010 1 n/a 1 0.6/1kV Black
AEI Rolling Stock A3UBK0015 1 n/a 1.5 0.6/1kV Black
AEI Rolling Stock A3UBK0025 1 n/a 2.5 0.6/1kV Black
AEI Rolling Stock A3UBK0040 1 n/a 4 0.6/1kV Black
AEI Rolling Stock A3UBK0060 1 n/a 6 0.6/1kV Black
AEI Rolling Stock A3UBK010 1 n/a 10 0.6/1kV Black
AEI Rolling Stock A3UBK016 1 n/a 16 0.6/1kV Black
AEI Rolling Stock A3UBK025 1 n/a 25 0.6/1kV Black
AEI Rolling Stock A3UBK035 1 n/a 35 0.6/1kV Black
AEI Rolling Stock A3UBK050 1 n/a 50 0.6/1kV Black
AEI Rolling Stock A3UBK070 1 n/a 70 0.6/1kV Black
AEI Rolling Stock A3UBK095 1 n/a 95 0.6/1kV Black
AEI Rolling Stock A3UBK120 1 n/a 120 0.6/1kV Black
AEI Rolling Stock A3UBK150 1 n/a 150 0.6/1kV Black
AEI Rolling Stock A3UBK185 1 n/a 185 0.6/1kV Black
AEI Rolling Stock A3UBK240 1 n/a 240 0.6/1kV Black
AEI Rolling Stock A3UBK300 1 n/a 300 0.6/1kV Black
AEI Rolling Stock A3UBK400 1 n/a 400 0.6/1kV Black
AEI Rolling Stock A3UBK0015/3KV 1 n/a 1.5 1.8/3kV Black
AEI Rolling Stock A3UBK0025/3KV 1 n/a 2.5 1.8/3kV Black
AEI Rolling Stock A3UBK0040/3KV 1 n/a 4 1.8/3kV Black
AEI Rolling Stock A3UBK0060/3KV 1 n/a 6 1.8/3kV Black
AEI Rolling Stock A3UBK010/3KV 1 n/a 10 1.8/3kV Black
AEI Rolling Stock A3UBK016/3KV 1 n/a 16 1.8/3kV Black
AEI Rolling Stock A3UBK025/3KV 1 n/a 25 1.8/3kV Black
AEI Rolling Stock A3UBK035/3KV 1 n/a 35 1.8/3kV Black
AEI Rolling Stock A3UBK050 1 n/a 50 1.8/3kV Black
AEI Rolling Stock A3UBK070/3KV 1 n/a 70 1.8/3kV Black
AEI Rolling Stock A3UBK095/3KV 1 n/a 95 1.8/3kV Black
AEI Rolling Stock A3UBK120/3KV 1 n/a 120 1.83kV Black
AEI Rolling Stock A3UBK150/3KV 1 n/a 150 1.8/3kV Black
AEI Rolling Stock A3UBK185/3KV 1 n/a 185 1.8/3kV Black
AEI Rolling Stock A3UBK240/3KV 1 n/a 240 1.8/3kV Black
AEI Rolling Stock A3UBK300/3KV 1 n/a 300 1.8/3kV Black
AEI Rolling Stock A3UBK400/3KV 1 n/a 400 1.8/3kV Black
LFH Rail Rolling Stock Part 6 Type I Cable - LUL Approved LULP6TI1X0.5 1 n/a 0.5 n/a Red
LFH Rail Rolling Stock Part 6 Type I Cable - LUL Approved LULP6TI1X0.75 1 n/a 0.75 n/a Red
LFH Rail Rolling Stock Part 6 Type I Cable - LUL Approved LULP6TI1X1 1 n/a 1 n/a Red
LFH Rail Rolling Stock Part 6 Type I Cable - LUL Approved LULP6TI1X1.5 1 n/a 1.5 n/a Red
LFH Rail Rolling Stock Part 6 Type I Cable - LUL Approved LULP6TI1X2.5 1 n/a 2.5 n/a Red
LFH Rail Rolling Stock Part 6 Type I Cable - LUL Approved LULP6TI1X4 1 n/a 4 n/a Red
LFH Rail Rolling Stock Part 6 Type II Cable - LUL Approved LULP6TII1X0.75 1 n/a 0.75 n/a Red
LFH Rail Rolling Stock Part 6 Type II Cable - LUL Approved LULP6TII1X1 1 n/a 1 n/a Red
LFH Rail Rolling Stock Part 6 Type II Cable - LUL Approved LULP6TII1X1.5 1 n/a 1.5 n/a Red
LFH Rail Rolling Stock Part 6 Type II Cable - LUL Approved LULP6TII1X2.5 1 n/a 2.5 n/a Red
LFH Rail Rolling Stock Part 6 Type II Cable - LUL Approved LULP6TII1X4 1 n/a 4 n/a Red
LFH Rail Rolling Stock Part 6 Type II Cable - LUL Approved LULP6TII1X6 1 n/a 6 n/a Red
LFH Rail Rolling Stock Part 6 Type II Cable - LUL Approved LULP6TII1X1 1 n/a 10 n/a Red
LFH Rail Rolling Stock Part 6 Type II Cable - LUL Approved LULP6TII1X16 1 n/a 16 n/a Red
LFH Rail Rolling Stock Part 6 Type II Cable - LUL Approved LULP6TII1X25 1 n/a 25 n/a Red
LFH Rail Rolling Stock Part 6 Type II Cable - LUL Approved LULP6TII1X35 1 n/a 35 n/a Red
LFH Rail Rolling Stock Part 6 Type II Cable - LUL Approved LULP6TII1X50 1 n/a 50 n/a Red
LFH Rail Rolling Stock Part 6 Type II Cable - LUL Approved LULP6TII1X70 1 n/a 70 n/a Red
LFH Rail Rolling Stock Part 6 Type II Cable - LUL Approved LULP6TII1X95 1 n/a 95 n/a Red
LFH Rail Rolling Stock Part 6 Type II Cable - LUL Approved LULP6TII1X150 1 n/a 150 n/a Red
LFH Rail Rolling Stock Part 6 Type II Cable - LUL Approved LULP6TII1X240 1 n/a 240 n/a Red
LFH Rail Rolling Stock Part 6 Type II Cable - LUL Approved LULP6TII1X300 1 n/a 300 n/a Red
LFH Rail Rolling Stock Part 6 Type III Cable - LUL Approved LULP6TIII1X50 1 n/a 50 n/a Red
LFH Rail Rolling Stock Part 6 Type III Cable - LUL Approved LULP6TIII1X70 1 n/a 70 n/a Red
LFH Rail Rolling Stock Part 6 Type III Cable - LUL Approved LULP6TIII1X95 1 n/a 95 n/a Red
LFH Rail Rolling Stock Part 6 Type III Cable - LUL Approved LULP6TIII1X150 1 n/a 150 n/a Red
LFH Rail Rolling Stock Part 6 Type III Cable - LUL Approved LULP6TIII1X185 1 n/a 185 n/a Red
LFH Rail Rolling Stock Part 6 Type III Cable - LUL Approved LULP6TIII1X240 1 n/a 240 n/a Red
LFH Rail Rolling Stock Part 6 Type III Cable - LUL Approved LULP6TIII1X300 1 n/a 300 n/a Red
LFH Rail Rolling Stock Part 6 Type IV Cable - LUL Approved LULP6TIV1X0.5V 1 n/a 0.5 n/a Violet
LFH Rail Rolling Stock Part 6 Type IV Cable - LUL Approved LULP6TIV1X0.75V 1 n/a 0.75 n/a Violet
LFH Rail Rolling Stock Part 6 Type IV Cable - LUL Approved LULP6TIV1X1V 1 n/a 1 n/a Violet
LFH Rail Rolling Stock Part 6 Type IV Cable - LUL Approved LULP6TIV1X1.5V 1 n/a 1.5 n/a Violet
LFH Rail Rolling Stock Part 6 Type IV Cable - LUL Approved LULP6TIV1X2.5V 1 n/a 2.5 n/a Violet
LFH Rail Rolling Stock Part 6 Type IV Cable - LUL Approved LULP6TIV1X4V 1 n/a 4 n/a Violet
LFH Rail Rolling Stock Part 6 Type IV Cable - LUL Approved LULP6TIV1X0.5Y 1 n/a 0.5 n/a Yellow
LFH Rail Rolling Stock Part 6 Type IV Cable - LUL Approved LULP6TIV1X0.75Y 1 n/a 0.75 n/a Yellow
LFH Rail Rolling Stock Part 6 Type IV Cable - LUL Approved LULP6TIV1X1Y 1 n/a 1 n/a Yellow
LFH Rail Rolling Stock Part 6 Type IV Cable - LUL Approved LULP6TIV1X1.5Y 1 n/a 1.5 n/a Yellow
LFH Rail Rolling Stock Part 6 Type IV Cable - LUL Approved LULP6TIV1X2.5Y 1 n/a 2.5 n/a Yellow
LFH Rail Rolling Stock Part 6 Type IV Cable - LUL Approved LULP6TIV1X4Y 1 n/a 4 n/a Yellow
LFH Rail Rolling Stock Part 6 Type V Cable - LUL Approved LULP6V1X0.5V 1 n/a 0.5 n/a Violet
LFH Rail Rolling Stock Part 6 Type V Cable - LUL Approved LULP6V1X0.75V 1 n/a 0.75 n/a Violet
LFH Rail Rolling Stock Part 6 Type V Cable - LUL Approved LULP6V1X1V 1 n/a 1 n/a Violet
LFH Rail Rolling Stock Part 6 Type V Cable - LUL Approved LULP6V1X1.5V 1 n/a 1.5 n/a Violet
LFH Rail Rolling Stock Part 6 Type V Cable - LUL Approved LULP6V1X2.5V 1 n/a 2.5 n/a Violet
LFH Rail Rolling Stock Part 6 Type V Cable - LUL Approved LULP6V1X4V 1 n/a 4 n/a Violet
LFH Rail Rolling Stock Part 6 Type V Cable - LUL Approved LULP6V1X6V 1 n/a 6 n/a Violet
LFH Rail Rolling Stock Part 6 Type V Cable - LUL Approved LULP6V1X10V 1 n/a 10 n/a Violet
LFH Rail Rolling Stock Part 6 Type V Cable - LUL Approved LULP6V1X0.5Y 1 n/a 0.5 n/a Yellow
LFH Rail Rolling Stock Part 6 Type V Cable - LUL Approved LULP6V1X0.75Y 1 n/a 0.75 n/a Yellow
LFH Rail Rolling Stock Part 6 Type V Cable - LUL Approved LULP6V1X1Y 1 n/a 1 n/a Yellow
LFH Rail Rolling Stock Part 6 Type V Cable - LUL Approved LULP6V1X1.5Y 1 n/a 1.5 n/a Yellow
LFH Rail Rolling Stock Part 6 Type V Cable - LUL Approved LULP6V1X2.5Y 1 n/a 2.5 n/a Yellow
LFH Rail Rolling Stock Part 6 Type V Cable - LUL Approved LULP6V1X4Y 1 n/a 4 n/a Yellow
LFH Rail Rolling Stock Part 6 Type V Cable - LUL Approved LULP6V1X6Y 1 n/a 6 n/a Yellow
LFH Rail Rolling Stock Part 6 Type V Cable - LUL Approved LULP6V1X10Y 1 n/a 10 n/a Yellow
LFH Rail Rolling Stock Part 6 Type VI Cable - LUL Approved LULP6TVI10X2.5 10 n/a 2.5 n/a Black with Yellow Stripe
LFH Rail Rolling Stock Part 6 Type VI Cable - LUL Approved LULP6TVI20X4 20 n/a 4 n/a Black with Yellow Stripe
LFH Rail Rolling Stock Part 6 Type VII Cable - LUL Approved LULP6TVII12X1 12 n/a 1 n/a Black with Yellow Stripe
LFH Rail Rolling Stock Part 6 Type VII Cable - LUL Approved LULP6TVII42X1.5 42 n/a 1.5 n/a Black with Yellow Stripe
LFH Rail Rolling Stock Part 6 Type VIII Cable - LUL Approved LULP6TVIII1P0.5 n/a 1 0.5 n/a Black
LFH Rail Rolling Stock Part 6 Type VIII Cable - LUL Approved LULP6TVIII1P0.75 n/a 1 0.75 n/a Black
LFH Rail Rolling Stock Part 6 Type VIII Cable - LUL Approved LULP6TVIII1P1 n/a 1 1 n/a Black
LFH Rail Rolling Stock Part 6 Type VIII Cable - LUL Approved LULP6TVIII2P1 n/a 2 1 n/a Black
LFH Rail Rolling Stock Part 6 Type VIII Cable - LUL Approved LULP6TVIII3P1 n/a 3 1 n/a Black
LFH Rail Rolling Stock Part 6 Type IX Cable - LUL Approved LULP6TIX1P0.5 n/a 1 0.5 n/a Black
LFH Rail Rolling Stock Part 6 Type IX Cable - LUL Approved LULP6TIX2P0.5 n/a 2 0.5 n/a Black
LFH Rail Rolling Stock Part 6 Type IX Cable - LUL Approved LULP6TIX1P1 n/a 1 1 n/a Black
LFH Rail Rolling Stock Part 6 Type IX Cable - LUL Approved LULP6TIX2P1 n/a 2 1 n/a Black
LFH Rail Rolling Stock Part 6 Type IX Cable - LUL Approved LULP6TIX3P1 n/a 3 1 n/a Black
LFH Rail Rolling Stock Part 6 Type IX Cable - LUL Approved LULP6TIX4P1 n/a 4 1 n/a Black
LFH Rail Rolling Stock Part 6 Type XI Cable - LUL Approved LULP6TXI1P1 n/a 1 1 n/a Black
LFH Rail Rolling Stock Part 6 Type XII Cable - LUL Approved LULP6TXII1C1 1 n/a 1 n/a Green
LFH Rail Rolling Stock Part 6 Type XII Cable - LUL Approved LULP6TXII1C1.5 1 n/a 1.5 n/a Green
LFH Rail Rolling Stock Part 6 Type XII Cable - LUL Approved LULP6TXII1C2.5 1 n/a 2.5 n/a Green
LFH Rail Rolling Stock Part 6 Type XII Cable - LUL Approved LULP6TXII1C4 1 n/a 4 n/a Green
LFH Rail Rolling Stock Part 6 Type XII Cable - LUL Approved LULP6TXII1C6 1 n/a 6 n/a Green
LFH Rail Rolling Stock Part 6 Type XIII Cable - LUL Approved LULP6TXIII12C1 12 n/a 1 n/a Black with Yellow Stripe
LFH Rail Rolling Stock Part 6 Type XIII Cable - LUL Approved LULP6TXIII42C1 42 n/a 1.5 n/a Black with Yellow Stripe
